NET FLYWHEELPOWER: 239 kW
OPERATING WEIGHT: 44970 kg
ENGINE MODEL: CAT C13 ACERT
BUCKET CAPACITY: 3.8m³
Key Specifications
Certified Working Hours:
1,200–1,500 operational hours (minimal wear, ideal for medium-duty projects like construction and mining).
Hydraulic systems rigorously tested under heavy-load conditions for leak-free performance.
Production Date:
Manufactured between 2018–2022, featuring Tier 4-compliant engines and reinforced structural durability.
Chassis and boom integrity verified with no prior repairs or cracks.
ACERT Technology works at the point of combustion to optimize engine performance and provide low exhaust emissions to meet EU Stage II emission regulations, with exceptional performance capabilities and proven reliability.
Outstanding performance. Excellent control, high stick and bucket forces, impressive lift capacity, simplified service and a more comfortable operator station to increase your productivity and lower operating costs.
|
Model |
CAT345DL |
|
Manufacturer |
CATERPILLAR |
|
Size |
Large - Scale |
|
Condition |
Used in good condition |
|
Operating Weight |
44970 kg |
|
Engine |
CAT C13ACERT |
|
No. of Cylinders |
6 |
|
Rated Power |
239 kW |
|
Displacement |
12503 cc |
|
Max. Travel Speed |
4.4 km/h |
|
Swing Speed |
7.9 rpm |
|
Shipping Height |
3590 mm |
|
Shipping Length |
1239 mm |
|
Tail Swing Radius |
3770 mm |
|
Ground Clearance |
510 mm |
|
Max. Loading Height |
7088 mm |
|
Max. Reach at Ground Level |
12960 mm |
|
Max. Digging Depth |
8920 mm |
|
Lifting Capacity Over Front |
4450 kg |
|
Lifting Capacity Over Side |
3450 kg |
|
Max. Cutting Height |
10320 mm |
|
Max. Vertical Wall Digging Depth |
5400 mm |
|
Warranty |
1 Year |
