RATED POWER: 77.5 kW
OPERATING WEIGHT: 15000 kg
ENGINE MODEL: ISUZU AR-4JJ1XASC
BUCKET CAPACITY: 0.55 m³
Key Specifications
Certified Working Hours:
4,000–5,500 operational hours (approx. 55-65% remaining lifespan), validated for construction, landscaping, and light industrial tasks.
Hydraulic systems and engine performance tested under peak loads to ensure leak-free operation.
Production Date:
Manufacturing Date (MFD): 2022, equipped with Tier 4-compliant engines and reinforced structural durability.
Boom, bucket linkage, and undercarriage inspected with no prior structural repairs or cracks reported
When equipped with quick coupler, operators can easily reduce the time it takes to change work tools giving convenience and flexibility in the field.
Easy to transport at a maximum legal load width of 102″
Steel track comes standard with the option of bolt-on rubber pads to make your machine street-ready for work on pavement or concrete
Minimal tail swing radius allows operation in extremely confined spaces
|
Model |
SY155C |
|
Manufacturer |
SANY |
|
Size |
Medium - Scale |
|
Condition |
Used in good condition |
|
Operating weight |
16000 kg 35,274lb |
|
Engine |
ISUZU AR-4JJ1XASC |
|
Displacement |
3.0 L |
|
Rated power/speed |
77.5 kW |
|
Travel speed |
3.1 / 5.3 km/hr |
|
Swing speed |
12 r/min |
|
Boom length |
4,600 mm |
|
Arm length |
2,500 mm |
|
Maximum digging height |
8,645 mm |
|
Maximum dumping height |
6,175 mm |
|
Maximum digging depth |
5,500 mm |
|
Minimum swing radius |
2,500 mm |
|
Transport Length |
8,178 mm |
|
Transport width |
2,590 mm |
|
Transport height |
2,820 mm |
|
Ground clearance (minimum) |
425 mm |
