ENGINE POWER: 578kW 775 HP / 1800 rpm
OPERATING WEIGHT: 115,900– 118,300 kg
BUCKET CAPACITY: 6.7 m³
Komatsu’s new U.S. EPA Tier 4 Final emission regulations-compliant engine
Fuel consumption reduced up to 7% (Comparison of PC1250-11 P mode and PC1250-8 P mode)
Further promotion of cleanliness and economy
Auto idle stop function
Productivity increased up to 8% (Comparison of PC1250-11 P+ mode and PC1250-8 P mode)
Large digging force
Enhanced efficiency due to powerful and smooth work
Highly durable and reliable Komatsu designed components
Operator’s cab OPG level 2 (ISO 10262)
Lock lever auto lock function
Rear and side view monitor system
Meticulous safety accessories throughout
Hydraulically operated stairway
Emergency stop switch
|
Model |
PC1250-11 |
|
Manufacturer |
KOMATSU |
|
Size |
Large-Scale |
|
Condition |
Used in good condition |
|
Operating Weight |
118200KG |
|
Ground Pressure |
1.08 kg/cm² |
|
Number of Cylinders |
6 |
|
Engine |
Komatsu SAA6D170E-7 |
|
Rated Power |
578 kW 775 HP |
|
Displacement |
2315 L |
|
Traveling Speed |
High : 3.3 km/h Low : 2.3 km/h |
|
Swing Speed |
5.8 rpm |
|
Gradeability |
70%, 35° |
|
Overall Length |
16070 mm |
|
Overall Height |
6040 mm |
|
Max. Digging Height |
11955 mm |
|
Max. Digging Radius |
13660 mm |
|
Max. Digging Depth |
8445 mm |
|
Warranty |
1 Year |
