RATED POWER: 75 kw
OPERATING WEIGHT: 8200 kg
ENGINE: YC4A105Z-T20
MC388 backhoe loader is a kind of construction machinery with small front wheel and big rear wheel launched by Weimeng Machinery.The engine of 388 backhoe loader is from Yuchai, the implementation standard is national second, the power is 75KW.The engine is a powerful and high-performance engine that provides great power for driving and working on the backhoe.This model is a whole frame structure, the body material is manganese steel, the body is sturdy and not easy to be damaged.
This model adopts the traditional mechanical operation, unlike the operation that relies on pilot valve control, the mechanical operation relies more on human power to control the working device by pulling the wire, so the action is more accurate and precise.
This model comes standard with air conditioning, which improves the driver's working conditions both in really hot areas and in cold weather.
The 388 backhoe loader is a cross between the regular 388 and the 388T. The performance is more superior than the ordinary 388, the body material is more solid, the work valve used in 388 is from China's first-class brand, and the cab has anti-roll performance, which is powerful in safety. Compared with 388T, the price of 388 is more moderate, and the domestic axle can also meet most of the work needs, which is a good choice for many customers at present.
MC388 Backhoe Loader |
||
1 |
Overall dimension(L×W×H) |
6230x2365x3752 |
2 |
Operating weight |
8200KG |
3 |
Wheel base |
2250mm |
4 |
Dumping Height |
2650mm |
5 |
Loading Bucket |
1.0m³ |
6 |
Backhoe Bucket |
0.3m³ |
7 |
Dumping Reach |
1025mm |
8 |
Max.Digging Depth |
4085mm |
9 |
Tire(Rear) |
19.5L-24 |
10 |
Tire(Front) |
14-17.5 |
Engine |
||
1 |
Model |
YC4A105Z-T20 |
2 |
Rated Power |
75kw/100hp |
3 |
Displacement |
4.3L |
