NET POWER: 231kw 1900rpm
OPERATING WEIGHT: 39000 kg
ENGINE MODEL: Komastu SA6D140E-3
Key Specifications & Highlights
Low Working Hours:
Operates with 1,200–6,500 certified working hours (equivalent to 50-60% remaining lifespan), ensuring extended productivity with minimal downtime.
Hydraulic systems and engine performance tested under heavy-load conditions for reliability.
Production Date:
Manufactured in 2013-2022, featuring modern engineering standards and compliance with Tier 4 emission
For the best value, reliability, and versatility. Hydraulics, power train, frame, and all other major components are engineered by Komatsu. You get a machine with components that are designed to work together to deliver higher production levels, greater reliability, and more versatility.
Controlled automatically, reduces fuel consumption and operating noise levels. Reverse position for cleaning radiator.
Provides excellent machine balance and low centre of gravity
Simple hull frame and monocoque track frame with pivot shaft for greater reliability.
The X-bogie design gives improved ground contact increasing the lifetime of the lubricated track.
Parameter |
D155AX-5 |
Overall weight |
39000 kg |
Engine |
Komastu SA6D140E-3 |
Rated power/rated speed |
231/1900 kW/rpm |
Overall length with dozer |
6300 mm |
Maximum torque |
160 kg·m @ 1.250 rpm |
Bore × stroke |
140 × 165 mm |
Displacement |
15,24 ltr |
Fuel tank capacity |
625 ltr |
Blade capacity |
8.8/11.8 m³ |
Emissions (Indicated as per international standards) |
Eu stageⅡ |
