GROSS POWER:123kW
OPERATING WEIGHT: 22500kg
ENGINE MODEL:VOLVO D6E
BUCKET CAPACITY: 0.52 – 1.22 m³
Featuring high swing speed and powerful Volvo engine, you can count on the EC220 Heavy Duty to get the job done. Keep uptime to a maximum thanks to long service intervals, robust design and easy maintenance, while operators can work in comfort and safety in the industry-renowned Volvo cab. The already impressive lifting and digging forces are increased further with power boost, resulting in faster cycle times and up to 8% higher productivity and up to 7% increase in fuel efficiency – even in the toughest conditions.
Low Working Hours:
Operates with 1,200–6,500 certified working hours (equivalent to 50-60% remaining lifespan), ensuring extended productivity with minimal downtime.
Hydraulic systems and engine performance tested under heavy-load conditions for reliability.
Production Date:
Manufactured in 2013-2022, featuring modern engineering standards and compliance with Tier 4 emission
Introducing the EC220 Heavy Duty. This new crawler excavator delivers up to 8% more productivity and up to a 7% improvement in fuel efficiency, without any compromise on power and performance.
The EC220 Heavy Duty is designed to keep operators safe, comfortable and working their best. Features including Volvo cab, outstanding visibility and a host of safety enhancements provide the industry-renowned levels of comfort and safety you would expect from Volvo.
Model |
EC220HD |
Manufacturer |
VOLVO |
Size |
Medium - Scale |
Condition |
Used in good condition |
Operating weight |
22500 kg |
Engine |
VOLVO D5E |
Displacement |
4.7 L |
Rated power |
123 kW |
Maximum torque |
670 Nm |
Cylinder bore x stroke |
108x130 mm |
Max. swing speed |
2.3 rpm |
Overall width |
2800 mm |
Overall length |
9745 mm |
Overall height of boom |
3080 mm |
Track length |
4160 mm |
Min. ground clearance |
460 mm |
